The Ioff circuitry disables the output, preventing the damaging backflow current through the device when it is powered down. This device is fully specified for partial power-down applications using Ioff. This feature allows the use of this device in a mixed 3.3 V and 5 V environment. The input can be driven from either 5 V devices. The is a high-performance, low-voltage, Si-gate CMOS device, superior to most advanced CMOS compatible TTL families. Single D-type flip-flop with reset positive-edge trigger >CMOS Low Power Consumption >Latch-up Performance Exceeds 250 ma >Direct Interface With TTL Levels >Inputs Accept Voltages up to 5 V >SOT363 And SOT457 Package >Specified From -40 Cel to +85Cel And -40 Cel to +125 Cel. >+-24 ma Output Drive (VCC = 3.0 V) >ESD Protection: >HBM EIA/JESD22-A114-A Exceeds 2000 V >MM EIA/JESD22-A115-A Exceeds 200 V. > Features Wide Supply Voltage Range From 1.65 V to 5.5 V >5 V Tolerant Inputs For Interfacing With 5 V Logic >High Noise Immunity >Complies With Jedec Standard: >JESD8-7 (1.65 V to 1.95 V) >JESD8-5 (2.3 V to 2.7 V) >JESD8B/JESD36 (2.7 V to 3.6 V). >Schmitt-trigger Action at All Inputs Makes The Circuit Highly Tolerant to Slower Input Rise And Fall Times. The D Input Must be Stable One Set-up Time Prior to The Low-to-high Clock Transition, For Predictable Operation. Information on The Data Input is Transferred to The Q Output on The Low-to-high Transition of The Clock Pulse. >The Master Reset (MR) is an Asynchronous Active Low Input And Operate Independently of The Clock Input. >The 74LVC1G175 is a Single Positive Edge Triggered D-type Flip-flop With Individual Data (D) Input, Clock (CP) Input, Master Reset (MR) Input, And Q Output. The Ioff Circuitry Disables The Output, Preventing The Damaging Backflow Current Through The Device When it is Powered Down. >This Device is Fully Specified For Partial Power-down Applications Using Ioff. This Feature Allows The Use of This Device in a Mixed 3.3 V And 5 V Environment. >The Input CAN be Driven From Either 3.3 V or 5 V Devices. Single D-type Flip-flop With Reset Positive-edge Trigger.>the 74LVC1G175 is a High-performance, Low-voltage, Si-gate CMOS Device, Superior to MOSt Advanced CMOS Compatible TTL Families.
